SAM1238-04
SAM1238-04
SAM1238-04
Favorite Products
SAM1238-04
SAM1238-04
Samtec Inc.
CONN RCPT 4POS 0.079 GOLD SMD


3,072
3,072 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Termination
Solder
Series
MMS
Features
-
Material Flammability Rating
-
Style
Board to Board or Cable
Number of Positions
4
Number of Positions Loaded
All
Operating Temperature
-55°C ~ 125°C
Number of Rows
1
Fastening Type
Push-Pull
Contact Finish - Post
Tin
Mfr
Samtec Inc.
Connector Type
Receptacle
Ingress Protection
-
Package
Tube
Contact Type
Female Socket
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Voltage Rating
-
Insulation Color
Black
Contact Shape
Square
Base Product Number
MMS-104
Pitch - Mating
0.079" (2.00mm)
Mounting Type
Surface Mount
Insulation Height
0.177" (4.50mm)
Contact Length - Post
-
Applications
-
Mated Stacking Heights
-
Insulation Material
Liquid Crystal Polymer (LCP)
Contact Finish Thickness - Post
-
Product Status
Active
Row Spacing - Mating
-
Contact Finish - Mating
Gold
Current Rating (Amps)
3.9A per Contact
Contact Material
Phosphor Bronze
