SAM1163-47
SAM1163-47
SAM1163-47
Favorite Products
SAM1163-47
SAM1163-47
Samtec Inc.
CONN RCPT 94POS 0.079 GOLD PCB



3,043
3,043 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Contact Finish Thickness - Post
3.00µin (0.076µm)
Fastening Type
Push-Pull
Contact Finish - Mating
Gold
Material Flammability Rating
UL94 V-0
Pitch - Mating
0.079" (2.00mm)
Product Status
Discontinued at Digi-Key
Contact Shape
Square
Base Product Number
CLT-147
Connector Type
Receptacle
Mated Stacking Heights
-
Features
-
Voltage Rating
-
Contact Material
Phosphor Bronze
Operating Temperature
-55°C ~ 125°C
Number of Positions Loaded
All
Mounting Type
Through Hole
Insulation Color
Black
Contact Finish - Post
Gold
Contact Type
Female Socket
Contact Length - Post
0.085" (2.16mm)
Package
Tube
Style
Board to Board
Ingress Protection
-
Mfr
Samtec Inc.
Current Rating (Amps)
4.1A per Contact
Number of Rows
2
Row Spacing - Mating
0.079" (2.00mm)
Termination
Solder
Insulation Height
0.083" (2.10mm)
Series
CLT
Number of Positions
94
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Applications
-
Insulation Material
Liquid Crystal Polymer (LCP)
