SAM1143-51
SAM1143-51
SAM1143-51
SAM1143-51
Favorite Products
SAM1143-51
SAM1143-51
Samtec Inc.
CONN HEADER SMD R/A 102P 0.8MM
3,096
3,096 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Base Product Number
FTE-151
Features
-
Number of Positions
102
Insulation Height
0.120" (3.05mm)
Contact Finish Thickness - Post
3.00µin (0.076µm)
Series
FTE
Package
Bulk
Mounting Type
Surface Mount, Right Angle
Contact Finish - Post
Gold
Operating Temperature
-55°C ~ 125°C
Insulation Color
Black
Shrouding
Unshrouded
Fastening Type
Push-Pull
Contact Shape
Square
Mfr
Samtec Inc.
Pitch - Mating
0.031" (0.80mm)
Product Status
Active
Termination
Solder
Contact Finish - Mating
Gold
Material Flammability Rating
UL94 V-0
Current Rating (Amps)
2.7A per Contact
Voltage Rating
-
Applications
-
Number of Rows
2
Row Spacing - Mating
0.047" (1.20mm)
Contact Length - Post
-
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Ingress Protection
-
Contact Type
Male Pin
Number of Positions Loaded
All
Style
Board to Board
Contact Length - Mating
0.075" (1.90mm)
Overall Contact Length
-
Contact Material
Phosphor Bronze
Connector Type
Header
Insulation Material
Liquid Crystal Polymer (LCP)
Mated Stacking Heights
-
