S9254
S9254
S9254
Favorite Products
S9254
S9254
CONN HEADER VERT 14POS 1MM
Headers, Male Pins
3,004
3,004 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Mounting Type
Through Hole
Overall Contact Length
0.228" (5.80mm)
Connector Type
Header
Contact Type
Male Pin
Row Spacing - Mating
0.039" (1.00mm)
Number of Positions Loaded
All
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Base Product Number
SMH150
Mfr
Sullins Connector Solutions
Style
Board to Board
Ingress Protection
-
Termination
Solder
Contact Shape
Square
Material Flammability Rating
UL94 V-0
Insulation Color
Black
Voltage Rating
-
Insulation Material
Liquid Crystal Polymer (LCP)
Operating Temperature
-40°C ~ 125°C
Contact Finish Thickness - Post
Flash
Product Status
Active
Number of Rows
2
Fastening Type
Push-Pull
Contact Length - Mating
0.071" (1.80mm)
Features
-
Applications
-
Package
Bag
Shrouding
Unshrouded
Contact Length - Post
0.098" (2.50mm)
Contact Material
Phosphor Bronze
Series
SMH
Pitch - Mating
0.039" (1.00mm)
Insulation Height
0.059" (1.50mm)
Current Rating (Amps)
1A
Number of Positions
14
Contact Finish - Mating
Gold
Contact Finish - Post
Gold
Mated Stacking Heights
-
