S2152-08
S2152-08
Favorite Products
S2152-08
S2152-08
CONN HEADER R/A 16POS 2.54MM
3,076
3,076 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Contact Finish Thickness - Mating
100.0µin (2.54µm)
Product Status
Obsolete
Applications
-
Package
Bulk
Contact Type
Male Pin
Mounting Type
Through Hole, Right Angle
Termination
Solder
Contact Finish - Post
Tin
Ingress Protection
-
Series
-
Contact Length - Mating
0.230" (5.84mm)
Insulation Material
Thermoplastic, Polyester
Material Flammability Rating
UL94 V-0
Voltage Rating
-
Connector Type
Header
Base Product Number
PTC08
Pitch - Mating
0.100" (2.54mm)
Number of Positions
16
Shrouding
Unshrouded
Overall Contact Length
-
Contact Material
Copper Alloy
Number of Rows
2
Row Spacing - Mating
0.100" (2.54mm)
Fastening Type
Push-Pull
Insulation Height
0.240" (6.10mm)
Contact Shape
Square
Insulation Color
Black
Current Rating (Amps)
3A
Style
Board to Board or Cable
Contact Length - Post
0.520" (13.21mm)
Contact Finish Thickness - Post
100.0µin (2.54µm)
Contact Finish - Mating
Tin
Mfr
Sullins Connector Solutions
Number of Positions Loaded
All
Operating Temperature
-
Mated Stacking Heights
-
Features
-
