S1011-14
S1011-14
Favorite Products
S1011-14
S1011-14
CONN HEADER VERT 14POS 2.54MM
PZC14SAAN.pdf
3,085
3,085 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Package
Bulk
Termination
Solder
Number of Positions
14
Insulation Color
Black
Pitch - Mating
0.100" (2.54mm)
Mfr
Sullins Connector Solutions
Product Status
Obsolete
Contact Shape
Square
Contact Material
Copper Alloy
Insulation Material
Thermoplastic, Polyester
Material Flammability Rating
UL94 V-0
Contact Type
Male Pin
Number of Positions Loaded
All
Contact Finish - Post
Tin
Ingress Protection
-
Base Product Number
PZC14
Series
-
Mounting Type
Through Hole
Contact Length - Post
0.120" (3.05mm)
Operating Temperature
-
Fastening Type
Push-Pull
Contact Length - Mating
0.230" (5.84mm)
Current Rating (Amps)
3A
Style
Board to Board or Cable
Shrouding
Unshrouded
Overall Contact Length
0.450" (11.43mm)
Contact Finish - Mating
Gold
Connector Type
Header
Row Spacing - Mating
-
Mated Stacking Heights
-
Applications
-
Number of Rows
1
Insulation Height
0.100" (2.54mm)
Contact Finish Thickness - Mating
10.0µin (0.25µm)
Features
-
Voltage Rating
-
Contact Finish Thickness - Post
100.0µin (2.54µm)
