HR2023
HR2023
HR2023
Favorite Products
HR2023
HR2023
Hirose Electric Co Ltd
CONN HEADER VERT 15POS 2MM
3,036
3,036 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Contact Finish - Mating
Tin
Insulation Color
Black
Number of Positions
15
Contact Length - Mating
0.122" (3.10mm)
Contact Type
Male Pin
Number of Rows
1
Insulation Height
0.197" (5.00mm)
Features
-
Material Flammability Rating
UL94 V-0
Row Spacing - Mating
-
Contact Finish Thickness - Mating
39.4µin (1.00µm)
Ingress Protection
-
Applications
-
Fastening Type
Push-Pull
Overall Contact Length
0.299" (7.60mm)
Contact Material
Brass
Mated Stacking Heights
5mm
Pitch - Mating
0.079" (2.00mm)
Termination
Press-Fit, Solder
Contact Length - Post
0.114" (2.90mm)
Series
DF3
Package
Bag
Number of Positions Loaded
All
Insulation Material
Polyamide (PA), Nylon
Current Rating (Amps)
3A
Contact Finish Thickness - Post
-
Mounting Type
Through Hole
Operating Temperature
-55°C ~ 105°C
Connector Type
Header
Style
Board to Board or Cable
Shrouding
Shrouded - 4 Wall
Contact Finish - Post
Tin
Base Product Number
DF3A
Mfr
Hirose Electric Co Ltd
Product Status
Active
Contact Shape
Square
Voltage Rating
-
