ED9772
ED9772
ED9772
ED9772
ED9772
Favorite Products
ED9772
ED9772
CONN RCPT 72POS 0.1 GOLD PCB


3,092
3,092 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Contact Material
Beryllium Copper
Contact Type
Female Socket
Applications
-
Contact Finish - Mating
Gold
Row Spacing - Mating
0.100" (2.54mm)
Insulation Color
Black
Insulation Height
0.165" (4.20mm)
Insulation Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Base Product Number
803-93
Package
Tube
Connector Type
Receptacle
Contact Length - Post
0.125" (3.18mm)
Features
-
Contact Finish Thickness - Post
200.0µin (5.08µm)
Series
803
Contact Shape
Circular
Pitch - Mating
0.100" (2.54mm)
Mounting Type
Through Hole
Contact Finish - Post
Tin-Lead
Number of Positions
72
Number of Positions Loaded
All
Mfr
Mill-Max Manufacturing Corp.
Termination
Solder
Operating Temperature
-55°C ~ 125°C
Current Rating (Amps)
4.5A
Voltage Rating
-
Number of Rows
2
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Product Status
Active
Style
Board to Board
Fastening Type
Push-Pull
Mated Stacking Heights
-
Ingress Protection
-
Material Flammability Rating
UL94 V-0
