ED4864-64
ED4864-64
ED4864-64
ED4864-64
ED4864-64
Favorite Products
ED4864-64
ED4864-64
CONN RCPT 64POS 0.1 GOLD PCB
3,053
3,053 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Insulation Height
0.071" (1.80mm)
Base Product Number
315-93
Number of Positions
64
Fastening Type
Push-Pull
Product Status
Active
Contact Type
Female Socket
Mated Stacking Heights
-
Current Rating (Amps)
3A
Applications
-
Package
Tube
Insulation Color
Black
Material Flammability Rating
UL94 V-0
Voltage Rating
100V, 150VDC
Insulation Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Contact Shape
Circular
Contact Material
Beryllium Copper
Pitch - Mating
0.100" (2.54mm)
Termination
Solder
Mfr
Mill-Max Manufacturing Corp.
Row Spacing - Mating
-
Contact Length - Post
0.095" (2.41mm)
Series
315
Connector Type
Receptacle
Style
Board to Board
Contact Finish - Mating
Gold
Operating Temperature
-55°C ~ 125°C
Mounting Type
Through Hole
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Number of Positions Loaded
All
Number of Rows
1
Contact Finish - Post
Tin
Ingress Protection
-
Features
-
Contact Finish Thickness - Post
200.0µin (5.08µm)
