A34835
A34835
A34835
A34835
Favorite Products
A34835
A34835
CONN HEADER VERT 5POS 3MM
2-1445093-4.pdf
10,059
10,059 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Mounting Type
Through Hole
Base Product Number
1445093
Overall Contact Length
-
Product Status
Active
Number of Rows
1
Row Spacing - Mating
-
Contact Finish Thickness - Post
100.0µin (2.54µm)
Contact Finish - Post
Tin
Features
Board Guide
Current Rating (Amps)
Varies by Wire Gauge
Style
Board to Cable/Wire
Fastening Type
Locking Ramp
Shrouding
Shrouded - 4 Wall
Contact Length - Mating
-
Contact Shape
Square
Mated Stacking Heights
-
Contact Type
Male Pin
Insulation Height
0.364" (9.25mm)
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Contact Material
Brass
Connector Type
Header
Contact Length - Post
0.125" (3.18mm)
Material Flammability Rating
UL94 V-0
Insulation Color
Black
Voltage Rating
250V
Series
Micro MATE-N-LOK
Pitch - Mating
0.118" (3.00mm)
Number of Positions Loaded
All
Contact Finish - Mating
Gold
Mfr
TE Connectivity AMP Connectors
Package
Tray
Number of Positions
5
Insulation Material
Polyamide (PA), Nylon
Operating Temperature
-40°C ~ 105°C
Ingress Protection
-
Termination
Press-Fit, Solder
Applications
General Purpose
