A33263
A33263
A33263
A33263
Favorite Products
A33263
A33263
CONN HEADER R/A 24POS 3MM
794620.pdf
3,092
3,092 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Current Rating (Amps)
Varies by Wire Gauge
Number of Rows
2
Applications
General Purpose
Shrouding
Shrouded - 4 Wall
Product Status
Active
Number of Positions
24
Number of Positions Loaded
All
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Operating Temperature
-40°C ~ 105°C
Insulation Color
Black
Termination
Solder
Overall Contact Length
-
Contact Type
Male Pin
Fastening Type
Locking Ramp
Series
Micro MATE-N-LOK
Package
Tray
Contact Length - Mating
-
Material Flammability Rating
UL94 V-0
Insulation Material
Polyamide (PA), Nylon
Mated Stacking Heights
-
Contact Finish Thickness - Post
100.0µin (2.54µm)
Mfr
TE Connectivity AMP Connectors
Row Spacing - Mating
0.118" (3.00mm)
Style
Board to Cable/Wire
Features
Board Lock
Base Product Number
794620
Mounting Type
Through Hole, Right Angle
Contact Length - Post
-
Insulation Height
0.290" (7.37mm)
Connector Type
Header
Pitch - Mating
0.118" (3.00mm)
Contact Shape
Square
Contact Finish - Post
Tin
Ingress Protection
-
Contact Finish - Mating
Gold
Contact Material
Brass
Voltage Rating
250V
