A28668
A28668
A28668
Favorite Products
A28668
A28668
CONN HEADER VERT 5POS 2.54MM
5-104362-1.pdf
3,096
3,096 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Insulation Material
Thermoplastic
Style
Board to Board or Cable
Overall Contact Length
0.550" (13.97mm)
Number of Rows
1
Contact Finish Thickness - Mating
15.0µin (0.38µm)
Contact Finish - Post
Tin-Lead
Ingress Protection
-
Material Flammability Rating
UL94 V-0
Voltage Rating
267V
Mfr
TE Connectivity AMP Connectors
Package
Tube
Number of Positions
5
Contact Length - Mating
0.230" (5.84mm)
Mounting Type
Through Hole
Contact Length - Post
0.130" (3.30mm)
Operating Temperature
-65°C ~ 105°C
Current Rating (Amps)
3A
Contact Finish - Mating
Gold
Features
Keying Slot
Fastening Type
Latch Holder
Insulation Height
0.535" (13.60mm)
Mated Stacking Heights
-
Pitch - Mating
0.100" (2.54mm)
Row Spacing - Mating
-
Number of Positions Loaded
All
Termination
Press-Fit, Solder
Contact Material
Brass
Insulation Color
Black
Product Status
Active
Contact Shape
Square
Contact Finish Thickness - Post
100.0µin (2.54µm)
Base Product Number
104362
Series
AMPMODU MTE
Connector Type
Header
Contact Type
Male Pin
Shrouding
Shrouded - 4 Wall
Applications
Automotive, General Purpose, Medical, Telecommunications
