1502860000
1502860000
Favorite Products
1502860000
1502860000
Weidmüller
TERM BLOCK PLUG 12POS STR 5.08MM
3,005
3,005 In Stock
More quantities are on the way.
Product Attributes
Type PARAMETERS
Pitch
0.200" (5.08mm)
Series
Omnimate BL
Color
Orange
Package
Bulk
Type
Plug, Female Sockets
Torque - Screw
0.4-0.5 Nm (3.5-4.4 Lb-In)
Number of Positions
12
Current - IEC
17A
Housing Material
Polybutylene Terephthalate (PBT), Glass Filled
Number of Levels
1
Wire Gauge or Range - AWG
14-26 AWG
Operating Temperature
-
Screw Size
-
Contact Tail Length
-
Mfr
Weidmüller
Header Orientation
-
Plug Wire Entry
180°
Termination Style
Screw - TOP Clamp
Voltage - IEC
400 V
Current - UL
10 A
Wire Gauge or Range - mm²
0.2-2.5mm²
Material Flammability Rating
UL94 V-0
Contact Material
Copper Alloy
Contact Mating Finish
Tin
Wire Strip Length
13mm
Mounting Type
Free Hanging (In-Line)
Voltage - UL
300 V
Features
Retention Latches (Non-Wire Side)
Insulation Height
0.480" (12.20mm)
Product Status
Active
Positions Per Level
12
Ingress Protection
-
